ISUZU NPR/700P Box Truck

Wheelbase	3360mm-5200mm
Drive	4X2/4X4
Engine model	4HK1
Engine horsepower	189HP-205HP
Load	5T-7T
Box volume	20.5 m³-34m³
Box material	Steel corrugated/aluminum flat/composite board

Inquire Now Next Product

Product Configuration

Box body	Using polyester wet board making process and fully enclosed polyurethane board bonding method, the thermal insulation performance reaches the national A-level standard.
Box board	The inner and outer wall panels are made of domestic high-quality nano-glass (non-light-absorbing, good heat insulation, strong hardness, and anti-oxidation), and the middle insulation material is imported polyurethane with no gap filling;
Chassis	The bottom of the box is an aluminum alloy patterned plate or, with a 150mm overall bend skirt, which has better protection and sealing performance
Accessories	The perimeter of the box is made of aluminum alloy edging, stainless steel corners, stainless steel door locks, 4 anti-collision rubbers, stainless steel door frames, stainless steel hinges, and energy-saving LED lights in the box.
Others	The thickness of the box can be selected, and the inner and outer wall panels can be selected from fiberglass, color steel, stainless steel, and aluminum alloy.
Process quality	The latest fully sealed insulation box, lightweight, high strength, high insulation, and long service life
Professional customization	Seven years of modification experience, free customization of modification plans can be made according to vehicle needs

Vehicle Diagram

Rain test
Imported insulation board
Pressure plate machine
Process quality
Professional customization
Stainless steel lock

Vehicle Diagram

Refrigerated Truck

Model	Cab type	WB	OAL	0W	OH	FOH	ROH	L	W	H
700P	Single row	3360	6200	2400	3500	1110	1730	4200	2200	2200
		3815	7000	2400	3500	1110	2075	5100	2200	2200
		4175	7600	2400	3500	1110	2315	5600	2200	2200
		4475	8050	2400	3500	1110	2465	6100	2200	2200
		5200	9050	2400	3500	1110	2740	7000	2200	2200
Note: The above dimensions are for reference and can be customized according to needs

Isuzu 700P Box Truck
wheelbase	3360	3815	4175	4475	5200
Box volume	20.5 m³	25 m³	27 m³	29.5 m³	34 m³
Cabinet size	4200×2200×2200	5100×2200×2200	5600×2200×2200	6100×2200×2200	7000×2200×2200
motor	189hp/205hp	189hp/205hp	189hp/205hp	189hp/205hp	189hp/205hp
Gearbox	Isuzu MLD	Isuzu MLD	Isuzu MLD	Isuzu MLD	Isuzu MLD
Cabinet material	Steel corrugated / aluminum flat / composite panel

Product name			Isuzu 700P Box Truck
Vehicle parameters	Wheelbase (mm)		3360	3815	4175	4475	5200
	Vehicle size()		6200X2400X3500	7000X2400X3500	7600X2400X3500	8050X2400X3500	8950X2400X3500
	Gross weight (Kg)		10550	10550	10550	10550	10550
	Curb weight (Kg)		4390	4730	4830	5000	5700
	Number of passengers in the cab		3	3	3	3	3
	Top speed		110	110	110	110	110
	Tire specifications		235/75R17.5 16PR	235/75R17.5 16PR	235/75R17.5 16PR	235/75R17.5 16PR	235/75R17.5 16PR
	Number of tires		6+1	6+1	6+1	6+1	6+1
	Emission standards		National 5, National 6	National 5, National 6	National 5, National 6	National 5, National 6	National 5, National 6
Transformation parameters	Transmission model		Isuzu MLD	Isuzu MLD	Isuzu MLD	Isuzu MLD	Isuzu MLD
	Gear gear		6Forward + 1 Reverse	6Forward + 1 Reverse	6Forward + 1 Reverse	6Forward + 1 Reverse	6Forward + 1 Reverse
	4HK1-TCG60	151kw/205hp	○	○	○	○	○
	4HK1-TCG61	139kw/189hp	○	○	○	○	○
Dedicated performance	Cabinet material	Steel corrugated	○	○	○	○	○
		Composite panels	○	○	○	○	○
		Aluminum flat plate	○	○	○	○	○
	One-sided door		○	○	○	○	○
	Double-leaf side doors		○	○	○	○	○
	Box volume		20.5 m³	25 m³	27 m³	29.5 m³	34 m³
	Cabinet size		4200×2200×2200	5100×2200×2200	5600×2200×2200	6100×2200×2200	7000×2200×2200
	Factory standards		The bottom plate is bent as a whole 150mm skirt, 304 stainless steel hardware, left and right side protection, rear protection, box rain test, reflective label	The bottom plate is bent as a whole 150mm skirt, 304 stainless steel hardware, left and right side protection, rear protection, box rain test, reflective label	The bottom plate is bent as a whole 150mm skirt, 304 stainless steel hardware, left and right side protection, rear protection, box rain test, reflective label	The bottom plate is bent as a whole 150mm skirt, 304 stainless steel hardware, left and right side protection, rear protection, box rain test, reflective label	The bottom plate is bent as a whole 150mm skirt, 304 stainless steel hardware, left and right side protection, rear protection, box rain test, reflective label
Note: Please contact us for detailed configuration for confirmation, support customization
