Box Truck
| Wheelbase | 3360mm |
| Drive motor model | TZ230XS001 |
| Generator power | 90KW |
| Load | 2T |
| Power battery storage capacity | 86.55kWh-100.46kWh |
| Cruising range | 435km-510km |
| Box volume | 18.8m³ |
Product Configuration
| Box body | Using polyester wet board making process and fully enclosed polyurethane board bonding method, the thermal insulation performance reaches the national A-level standard. | |||
| Box board | The inner and outer wall panels are made of domestic high-quality nano-glass (non-light-absorbing, good heat insulation, strong hardness, and anti-oxidation), and the middle insulation material is imported polyurethane with no gap filling; | |||
| Chassis | The bottom of the box is an aluminum alloy patterned plate or, with a 150mm overall bend skirt, which has better protection and sealing performance | |||
| Accessories | The perimeter of the box is made of aluminum alloy edging, stainless steel corners, stainless steel door locks, 4 anti-collision rubbers, stainless steel door frames, stainless steel hinges, and energy-saving LED lights in the box. | |||
| Others | The thickness of the box can be selected, and the inner and outer wall panels can be selected from fiberglass, color steel, stainless steel, and aluminum alloy. | |||
| Process quality | The latest fully sealed insulation box, lightweight, high strength, high insulation, and long service life | |||
| Professional customization | Seven years of modification experience, free customization of modification plans can be made according to vehicle needs | |||
Vehicle Diagram
Rain test
Imported insulation board
Pressure plate machine
Process quality
Professional customization
Stainless steel lock
Vehicle Diagram
| Model | Cab type | WB | OAL | 0W | OH | FOH | ROH | L | W | H |
| EVM100 | Single row | 3360 | 5995 | 2230 | 3225 | 1145 | 1490 | 4250 | 2100 | 2100 |
| Note: The above dimensions are for reference and can be customized according to needs | ||||||||||
| Isuzu EVM100 Box Truck | |
| wheelbase | 3360 |
| Box volume | 18.8 m³ |
| Cabinet size | 4250×2100×2100 |
| Drive System (kw/rpm) | 65/140，90/167 |
| Cruising range (km) | 435km/510km |
| Cabinet material | Steel corrugated / composite board / aluminum flat plate |
| Product name | Isuzu EVM100 Box Truck | |||
| Vehicle parameters | Wheelbase (mm) | 3360 | ||
| Vehicle size() | 5995X2220X3225 | |||
| Gross weight (Kg) | 8280 | |||
| Curb weight (Kg) | 3565 | |||
| Number of passengers in the cab | 2 | |||
| Top speed | 98 | |||
| Tire specifications | 7.50R16LT 14PR | |||
| Number of tires | 6+1 | |||
| Drive System | Model | TZ230XS001 | TZ220XSA10 | |
| Type | Permanent magnet synchronous motor | Permanent magnet synchronous motor | ||
| Rated/peak power (kw/rpm) | 90/167 | 65/140 | ||
| Rated/peak torque (N.m/rpm) | 214/420 | 170/360 | ||
| Power battery | Type | Lithium iron phosphate | ||
| Energy Density Wh/kg | 159.56 | 150.01 | ||
| Total power storage（kWh） | 100.46 Ningde | 86.55 Ningde | ||
| Recharge mileage（km) | 510 Full load isokinetic method | 435 Full load isokinetic method | ||
| Dedicated performance | Cabinet material | Steel corrugated | ○ | |
| Composite panels | ○ | |||
| Aluminum flat plate | ○ | |||
| One-sided door | ○ | |||
| Double-leaf side doors | ○ | |||
| Box volume | 18.8 m³ | |||
| Cabinet size | 4250×2100×2100 | |||
| Factory standards | The bottom plate is bent as a whole 150mm skirt, 304 stainless steel hardware, left and right side protection, rear protection, box rain test, reflective label | |||
| Note: Please contact us for detailed configuration for confirmation, support customization | ||||
